Compact cargo bike designed to safely carry 2 kids.
Compact cargo bike designed to safely carry 2 kids.
Tern

Tern Quick Haul Long D9 E-Cargo Bike In Traffic Red

$3,799.00
Size Guide
Earn
in Customer Rewards when you buy this item today
Sign Up
Sign In
Tern Quick Haul Long D9 E-Cargo Bike In Satin Black
Preorder

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritized (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or dispatch to you — it often never even hits the stock room shelves!

Prelaunch

With Prelaunch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Preorders.

So, instead, you can submit your email address for the item you are interested in, and we will email you as soon as stock arrives in the system.

Estimated Shipping & Collection Dates

Estimated Shipping & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indicative purposes only and can change at any time without notice.

The dates we provide are based on information given by our suppliers. Whenever we get updated information from our suppliers we will endeavor to update the Estimated Shipping & Collection Dates provided on product pages.

We estimate this will be ready for dispatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Tern Quick Haul Long D9 E-Cargo Bike In Traffic Red

Brand:Tern

Code:12-9-31

Compact cargo bike designed to safely carry 2 kids.

Features:

  • Powerful Bosch Cargo Line motor provides up to 85 Nm of torque and up to 400% support
  • Easy-to-use, intuitive Bosch e-bike system helps you stay informed and in control on the road
  • Custom 1 x 9-speed e-bike drivetrain with trigger shifter for faster, more precise shifting
  • Built tough for hauling, rated to a maximum gross vehicle weight of 190 kg (419 lb) with a rear rack load capacity of 90 kg (198 lb)
  • Robust, patented Atlas Kickstand keeps the bike steady for safe loading & unloading of cargo and passengers
  • Create customized setups using our wide range of kid & cargo-carrying accessories
  • Adjusts without tools to fit riders 155 - 185 cm (5'1" - 6'1"), weighing up to 120 kg (265 lb)

Technical Information
  • Speeds
    1 x 9
  • Weight
    29.3 kg (64.6 lb)
  • Gear Inches
    23" - 89" (1.87 - 7.13 m)
  • Frame Sizes
    One size
  • Distance: Seatpost to Handlebar
    60 - 64 cm (23.6 - 25.2 in)
  • Distance: Saddle to Pedal
    76 - 99 cm (29.9 - 39 in)
  • Suggested Rider Height
    155 - 185 cm (61 - 72.8 in)
  • Max Gross Vehicle Weight
    190 kg (418.9 lb)
  • Max Rider Weight
    120 kg (264.6 lb)
  • Frame
    Tern Quick Haul Long, Patented Design, 6061-AL, DIN 79010 certified: 190 kg (419 lb)
  • Fork
    Cargo, Aluminum alloy, DIN 79010 certified: 190 kg (419 lb)
  • Stem
    Speedlifter, adjustable, 3D forged stem, 31.8
  • Headset
    TH, cartridge bearings
  • Handlebar
    Low riser ergo, 31.8, 6061-AL
  • Grips/Bar Tape
    Velo ergonomic, lock-on
  • Saddle
    Velo Comfort
  • Seatpost
    34.9 mm, 6061-AL, micro-adjust clamp
  • Seatpost Clamp
    Tern Collar
  • Front Brake
    Tektro hydraulic disk
  • Rear Brake
    Tektro hydraulic disk
  • Brake Levers
    Tektro hydraulic disk
  • Front Hub
    Disk, aluminum
  • Rear Hub
    9 spd, disk, aluminum, Boost
  • Spokes & Nipples
    Stainless steel
  • Rims
    Tern Atlas H, cargo
  • Tires
    Schwalbe Pick Up, 60-406, Super Defense puncture protection, Reflex
  • Shifter(s)
    Tektro, 1 x 9 spd, trigger
  • Rear Derailleur
    Tektro custom for Tern, 1 x 9 spd
  • Crankset
    Tern custom, forged 6061-AL crankarm, anti-drop chainring
  • Cassette/Freewheel
    Tektro 11-42T, 9 spd
  • Bottom Bracket
    Motor integrated
  • Chain
    KMC for eBike, 9 spd
  • Pedals
    Urban with non-slip surface
  • Shifter Cable & Housing
    SP
  • Motor
    Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
  • Battery
    Bosch PowerPack 500
  • Display
    Bosch Purion, 4 mode selectable, walk assist
  • Range
    500 Wh: 42-85 km (26-53 mi)
  • Charger
    220V, 4A (EU); 100-240V, 4A (US)
  • Bell
    Aluminum
  • Chainguard
    SKS Chainblade
  • Kickstand
    Atlas Kickstand, for cargo
  • Luggage Socket
    Combo Mount
  • Front Light
    90 lux, StVZO approved
  • Rear Light
    Herrmans
  • Fenders
    SplashGuard, stainless hardware
  • Rack(s)
    Atlas L, 90 kg (198 lb) capacity
  • Frame Lock
    ABUS or AXA, keyed-alike with Bosch battery
